HP XP7 Configuration Guide

Setting the disk and device parameters
The queue depth parameter (max_throttle) for the devices must be set according to one of the
options specified in Table 18 (page 72).
Table 18 Max throttle (queue depth) requirements for the devices (Solaris)
RequirementsQueue depth option
XP7: Queue_depth 2048 default.
Option 1
CAUTION: The number of issued commands must be
completely controlled. Because queuing capacity of the
disk array is 2048 per port , you must adjust the number
of issued commands from Solaris system to less than 2048.
Otherwise, memory allocate failed messages may occur
on the Solaris system, and all read/write I/O may stop,
causing the system to hang.
XP7: Number of LUs x queue_depth 2048 and
queue_depth 32
Option 2 (preferred)
NOTE: You can adjust the queue depth for the devices later as needed (within the specified
range) to optimize the I/O performance.
The required I/O time-out value (TOV) for devices is 60 seconds (default TOV=60). If the I/O TOV
has been changed from the default, change it back to 60 seconds by editing the sd_io_time
or ssd_io_time parameter in the /etc/system file.
You may also need to set several other parameters (such as FC fibre support). See the user
documentation that came with your FCA to determine whether other options are necessary to meet
your operational requirements.
NOTE: Use the same settings and device parameters for all systems. For Fibre Channel, the
settings in the system file apply to the entire system, not to just the FCAs.
To set the I/O TOV and queue depth for the devices:
1. Make a backup of the /etc/system file: cp /etc/system /etc/system.old.
2. To assure you use the default TOV, make sure that no sd_io_time values are set in the
/etc/system file or modify the /etc/system file to show the following values:
set sd:sd_io_time=0x3c
set ssd:ssd_io_time=0x3c for Oracle generic FCA
3. To set the queue depth, add the following to the /etc/system file:
set sd:sd_max_throttle = x
set ssd:ssd_max_throttle = x for Oracle generic FCA
(for x value, see Table 18 (page 72))
Example:
set sd:sd_max_throttle = 16 <— Add this line to /etc/system
set ssd:ssd_max_throttle = 16 <— Add this line to /etc/system (for Oracle generic FCA)
Configuring FCAs with the Oracle SAN driver stack
Oracle branded FCAs are only supported with the Oracle SAN driver stack. The Oracle SAN
driver stack also supports current Emulex and QLogic FCAs.
NOTE: Ensure host group mode 7 is set for the XP7 array ports where the host is connected to
enable automatic LUN recognition using this driver.
72 Solaris
