6 CONTROLS 14
6.11 Idle speed adjusting screw
F00046-10
The idle setting of the throttle valve body has a big influence on the vehicle's starting
behavior, on stable idling, and on vehicle response when the throttle is opened.
An engine with a correctly set idle speed is easier to start than an engine with the idle
speed set incorrectly.
The idle speed is adjusted using idle speed adjusting screw
(red).
Increase the idle speed by turning the idle speed adjusting screw clockwise.
Decrease the idle speed by turning the idle speed adjusting screw counterclockwise.
6.12 Shift lever
401950-10
Shift lever
is mounted on the left of the engine.
401950-13
The gear positions can be seen in the figure.
The neutral or idle position is between the first and second gears.
6.13 Foot brake lever
401956-10
Foot brake lever
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
