11 SERVICE WORK ON THE CHASSIS 46
11.21 Mounting the seat
H01402-10
Main work
– Mount the front of the seat on the collar bushing and the rear in the bracket.
– Push the seat forward.
– Make sure that the seat is correctly locked in.
–
Mount and tighten screw
.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the air filter box cover. ( p. 46)
11.22 Removing the air filter box cover
E00261-10
–
Pull off the air filter box cover sideways in areas
,
and
, and remove
toward the front.
11.23 Installing the air filter box cover
E00262-10
–
Position air filter box cover on collar bushings
and
and push toward the
rear.
–
Engage the air filter box cover in areas
,
and
.
