ELECTRICAL SYSTEM 15
117
H03758-10
–
Position protection cap
2
and turn all the way clockwise
using a coin.
– Press any button on the combination instrument.
The combination instrument is activated.
– Position the combination instrument in the holder.
– Mount and tighten the screws with washers.
Finishing work
– Install the headlight mask with the headlight. ( p. 113)
– Check the headlight setting. ( p. 115)
– Set the combination instrument. ( p. 27)
15.13 Diagnostics connector
H00933-12
Diagnostics connector
1
is located under the seat below the
EFI control unit.
