CONTROLS 6
21
6.5 Emergency OFF switch
A00362-10
The emergency OFF switch
1
is fitted on the right side of the
handlebar.
Possible states
Ignition off – In this position, the ignition circuit
is interrupted, a running engine stops, and a
non-running engine will not start.
Ignition on – In this position, the ignition circuit is
closed and the engine can be started.
6.6 Start button
A00362-11
Start button
1
is fitted on the right side of the handlebar.
Possible states
• The start button is in the basic position
• The start button is pressed – In this position, the starter
motor is actuated.
6.7 Horn button
K00599-12
Horn button
1
is fitted on the left side of the handlebar.
Possible states
• The horn button is in the basic position
• The horn button is pressed – The horn is operated in this
position.
6.8 Light switch
K00599-10
The light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – The light switch is turned down-
ward. In this position, the low beam and tail light are
switched on.
High beam on – The light switch is turned upward.
In this position, the high beam and the tail light are
switched on.
