Icom IC-R6 User Manual

13
New2001
BASIC OPERATION
4
■ Receiving
Make sure charged Ni-MH or brand new alkaline batteries
are installed. (p. 7)
q Hold down [ ] for 1 second to turn power ON.
w Push [p] or [q] to set a desired audio level.
• The function display shows the volume level while setting. See
the section to the right for details.
e Set the receive frequency. (p. 11)
r Set the squelch level. (p. 14)
• While holding down [SQL], rotate [DIAL].
• The first click of [DIAL] indicates the current squelch level.
• “LEVEL 1” is loose squelch and “LEVEL 9” is tight squelch.
• “AUTO” indicates automatic level adjustment using a noise
pulse count system.
• Hold down [SQL] to open the squelch manually.
t When a signal is received:
• The squelch opens and audio is heard.
• The S-meter shows the relative signal strength.
q Power ON
[ ]
e Set frequency
r Set squelch level
w Set audio level
e Select band
r Push for setting
the squelch
(Push to monitor)
■ Setting audio volume
The audio level can be adjusted through 40 levels.
➥ P ush [p] or [q] to adjust the audio level.
• A beep tone sounds while adjusting. The tone sound lets you
know the approximate sound level.
• Holding down either key will continuously change the audio
level.
• Holding down [p] or [q], then rotating [DIAL] will also adjust
the audio level.
• The display shows the volume level while setting.
AUDIO LEVEL
Minimum level
(no audio)
Maximum level
Initial setting
DISPLAY

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
