Icom IC-R6 User Manual

41
New2001
TONE SQUELCH AND POCKET BEEP
8
■ Tone squelch frequency/DTCS code setting
D Tone and DTCS squelches
The tone squelch (CTCSS) or DTCS squelch opens only
when receiving a signal containing a matching subaudible
tone or DTCS code, respectively. You can silently wait for a
specified signal using the same tone or code.
D Reverse tone/DTCS squelch
The reverse tone/DTCS squelch is convenient if you want
to ignore a specific signal. The receiver mutes the squelch
when a signal with the matched tone or code is received.
“T SQL-R” / “DTCS -R” is displayed when the reverse tone
squelch/reverse DTCS squelch is set.
D Pocket beep
These functions use subaudible tones or DTCS codes for
calling and can be used as a “common pager” to inform you
that someone has called while you were away from the re-
ceiver.
D Setting subaudible tones for tone squelch
88.5 Hz and 023 are set as the defaults for the tone squelch
frequency and the DTCS code, respectively. Other frequen-
cies and codes can be selected as desired.
q Hold down [SET](TS) for 1 second to enter the Set mode.
w Rotate [DIAL] to select the “EXPAND” item.
e While holding down [FUNC], rotate [DIAL] to turn the
Expand set mode ON.
r Rotate [DIAL] to select the “TONE” item when selecting
the tone squelch frequency; select the “CODE” item when
selecting the DTCS code.
Tone squelch frequency selection
DTCS code selection
After 1 sec.
After 1 sec.
t While holding down [FUNC], rotate [DIAL] to select a
desired subaudible tone frequency or DTCS code.
• See the next page for details of available tone frequencies or
DTCS codes.
y Push [SET](TS) to exit the Set mode.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
