OTHER FUNCTIONS
New2001
■ Data cloning
Cloning allows you to quickly and easily transfer the pro-
grammed contents from one receiver to another; or data from
a personal computer to a receiver, using the optional CS-R6
cloning software and the appropriate cloning cable.
D Cloning between receivers
q Connect the OPC-474 cloning cable to the [SP] jack of the
master and sub-receivers.
• The master receiver is used to send data to the sub-receiver.
to [SP]
Master
receiver
Sub
receiver
to [SP]
NOTE: DO NOT push any key on the sub-receiver during
cloning. This will cause a cloning error.
w Hold down [V/M] of only the master receiver, and then
turn it ON. For the sub-receiver, simply turn it ON. (See
below for more information.)
“CLONE” and “m” appear
when entered the cloning
mode.
Master receiver
✔ CLONING MODE ENTRY (except Master receiver):
When the CI-V baud rate (p. 56) is selected any other than
“9600” or “AUTO,” the following operations are required.
q Turn the receiver’s power OFF.
w While holding down [MODE], push and hold [ ] for 1 sec-
ond to enter the cloning mode.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
