Icom IC-R6 User Manual

66
11
CONTROL COMMAND
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
• Audio volume level (Command: 14 01)
VR level Data VR level Data VR level Data
0 (min) 0000–0005 14 0090–0095 28 0179–0185
1 0006–0012 15 0096–0101 29 0186–0191
2 0013–0018 16 0102–0108 30 0192–0197
3 0019–0025 17 0109–0114 31 0198–0204
4 0026–0031 18 0115–0121 32 0205–0210
5 0032–0037 19 0122–0127 33 0211–0217
6 0038–0044 20 0128–0133 34 0218–0223
7 0045–0050 21 0134–0140 35 0224–0229
8 0051–0057 22 0141–0146 36 0230–0236
9 0058–0063 23 0147–0153 37 0237–0242
10 0064–0069 24 0154–0159 38 0243–0249
11 0070–0076 25 0160–0165 39 0250–0255
12 0077–0082 26 0166–0172
13 0083–0089 27 0173–0178
• Squelch level (Command: 14 03)
SQL level Data SQL level Data
OPEN 0000–0022 LEVEL5 0140–0162
AUTO 0023–0045 LEVEL6 0163–0185
LEVEL1 0046–0069 LEVEL7 0186–0208
LEVEL2 0070–0092 LEVEL8 0209–0231
LEVEL3 0093–0115 LEVEL9 0232–0255
LEVEL4 0116–0139
• S-meter level (Command: 15 02)
S-meter Data S-meter Data S-meter Data
- 0000 5 0080 Full 0160
1 0016 7 0112
3 0048 9 0144
• Tone squelch frequency setting (Command: 1B 01)
See page 52 for available tone frequencies for details.
q* w e
00 X X XX
100Hz digit: 0–2 10 Hz digit: 0–9 1 Hz digit: 0–9 0.1 Hz digit: 0–9 Fixed digit: 0* Fixed digit: 0*
*Not necessary when setting a frequency.
• DTCS code with polarity setting (Command: 1B 02)
See page 52 for available DTCS codes for details.
100 digit: 0–7 10 digit: 0–7 1 digit: 1–7 Fixed digit: 0 Fixed digit: 0 RX polarity digit: 0, 1*
q
0 0X X X
w e
X
* 0=Normal, 1=Reverse
Not necessary when the normal polarity is set

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
