MD380 User Manual
- 148 -
If a command source has a bound frequency source, the frequency source set in F0-03 to
F0-07 no longer takes effect when the command source is effective.
Function Code Parameter Name Setting Range Default
F0-28 Serial communication protocol
0: Modbus protocol
1: PROFIBUS-DP bridge
2: CANopen bridge
0
The MD380 supports Modbus, PROFIBUS-DP bridge and CANopen bridge. Select a proper
protocol based on the actual requirements.
Group F1: Motor 1 Parameters
Function Code Parameter Name Setting Range Default
F1-00
Motor type
selection
0: Common asynchronous motor
1: Variable frequency asynchronous motor
2: Permanent magnetic synchronous motor
1
F1-01
Rated motor
power
0.1–1000.0 kW
Model
dependent
F1-02
Rated motor
voltage
1–2000 V
Model
dependent
F1-03
Rated motor
current
0.01–655.35 A (AC drive power ≤ 55 kW)
0.1–6553.5 A (AC drive power > 55 kW)
Model
dependent
F1-04
Rated motor
frequency
0.01 Hz to maximum frequency
Model
dependent
F1-05
Rated motor
rotational speed
1–65535 RPM
Model
dependent
Set the parameters according to the motor nameplate no matter whether V/F control or
vector control is adopted.
To achieve better V/F or vector control performance, motor auto-tuning is required. The
motor auto-tuning accuracy depends on the correct setting of motor nameplate parameters.
Function Code Parameter Name Setting Range Default
F1-06
Stator resistance
(asynchronous motor)
0.001–65.535
Ω
(AC drive power ≤ 55 kW)
0.0001–6.5535
Ω
(AC drive power > 55 kW)
Model
dependent
F1-07
Rotor resistance
(asynchronous motor)
0.001–65.535
Ω
(AC drive power ≤ 55 kW)
0.0001–6.5535
Ω
(AC drive power > 55 kW)
Model
dependent
F1-08
Leakage inductive
reactance
(asynchronous motor)
0.01–655.35 mH (AC drive power ≤ 55 kW)
0.001–65.535 mH (AC drive power > 55 kW)
Model
dependent
