MD380 User Manual Desc
ription of Function Codes
- 161 -
Group F4: Input Terminals
The MD380 provides ve DI terminals (DI5 can be used for high-speed pulse input) and two
analog input (AI) terminals. The optional extension card provides another ve DI terminals
(DI6 to DI10) and an AI terminal (AI3).
Function Code Parameter Name Default Remark
F4-00 DI1 function selection 1: Forward RUN (FWD) Standard
F4-01 DI2 function selection 4: Forward JOG (FJOG) Standard
F4-02 DI3 function selection 9: Fault reset (RESET) Standard
F4-03 DI4 function selection 12: Multi-reference terminal 1 Standard
F4-04 DI5 function selection 13: Multi-reference terminal 2 Standard
F4-05 DI6 function selection 0 Extended
F4-06 DI7 function selection 0 Extended
F4-07 DI8 function selection 0 Extended
F4-08 DI9 function selection 0 Extended
F4-09 DI10 function selection 0 Extended
The following table lists the functions available for the DI terminals.
Table 6-1 Functions of DI terminals
Value Function Description
0 No function Set 0 for reserved terminals to avoid malfunction.
1 Forward RUN (FWD)
The terminal is used to control forward or reverse RUN
of the AC drive.
2 Reverse RUN (REV)
3 Three-line control
The terminal determines three-line control of the AC
drive. For details, see the description of F4-11.
4 Forward JOG (FJOG)
FJOG indicates forward JOG running, while RJOG
indicates reverse JOG running. The JOG frequency,
acceleration time and deceleration time are described
respectively in F8-00, F8-01 and F8-02.
5 Reverse JOG (RJOG)
6 Terminal UP If the frequency is determined by external terminals, the
terminals with the two functions are used as increment
and decrement commands for frequency modication.
When the frequency source is digital setting, they are
used to adjust the frequency.
7 Terminal DOWN
8 Coast to stop
The AC drive blocks its output, the motor coasts to rest
and is not controlled by the AC drive. It is the same as
coast to stop described in F6-10.
9 Fault reset (RESET)
The terminal is used for fault reset function, the same
as the function of RESET key on the operation panel.
Remote fault reset is implemented by this function.
