Selection and Dimensions MD380 User Manual
- 276 -
8.4 Selection of Peripheral Electrical Devices
Table 8-14 Selection of peripheral electrical devices of the MD380
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
Cable of Output
Side Main Circuit
(mm
2
)
Cable of Control
Circuit
(mm
2
)
Single-phase 220 V
MD380S0.4GB 10 9 0.75 0.75 0.5
MD380S0.7GB 16 12 0.75 0.75 0.5
MD380S1.5GB 25 18 1.5 1.5 0.5
MD380S2.2GB 32 25 2.5 2.5 0.5
Three-phase 220 V
MD380-2T0.4GB 6 9 0.75 0.75 0.5
MD380-2T0.75GB 10 9 0.75 0.75 0.5
MD380-2T1.5GB 10 9 0.75 0.75 0.5
MD380-2T2.2GB 16 12 1.5 1.5 0.5
MD380-2T3.7GB 20 18 2.5 2.5 0.75
MD380-2T5.5GB 40 32 4.0 4.0 0.75
MD380-2T7.5GB 50 38 6.0 6.0 0.75
MD380-2T11G 63 50 10 10 0.75
MD380-2T15G 100 65 16 16 0.75
MD380-2T18.5G 100 80 25 25 1.0
MD380-2T22G 125 95 35 35 1.0
MD380-2T30G 160 115 50 50 1.0
MD380-2T37G 225 170 70 70 1.0
MD380-2T45G 250 205 95 95 1.0
MD380-2T55G 315 245 120 120 1.0
MD380-2T75G 500 300 150 150 1.0
Three-phase 380 V
MD380T0.7GB 6 9 0.75 0.75 0.5
MD380T1.5GB 10 9 0.75 0.75 0.5
MD380T2.2GB 10 9 0.75 0.75 0.5
MD380T3.7GB 16 12 1.5 1.5 0.5
MD380T5.5 GB 20 18 2.5 2.5 0.75
MD380T7.5 GB 32 25 4.0 4.0 0.75
MD380T11GB 40 32 4.0 4.0 0.75
MD380T15GB 50 38 6.0 6.0 0.75
MD380T18.5G 50 40 10 10 1.0
MD380T22G 63 50 10 10 1.0
