iv
LBK System| Instruction manual v1.3 SEP 2019 |LBK-System_instructions_en v1.3|© 2018-2019 Inxpect SpA
Glossary of terms
D
Dangerous area
Area to be monitored because it is dangerous for people.
Detection area
Portion of the field of vision where detection is guaranteed.
F
Field of vision
Sensor area of vision. It is composed of two areas: detection area and uncertainty area. It can have
two ranges: 110° and 50°.
FMCW
Frequency Modulated Continuous Wave.
M
Machinery
The system for which the dangerous area is monitored.
Monitored area
Area actually monitored by the system. Includes the stopping area, and only for the access
detection function, any pre-alarm area.
P
Pre-alarm area
Only for the access detection function. Area where motion detection triggers the closure of the
dedicated auxiliary relay.
R
Rotation
Sensor rotation around the transverse axis. The sensor inclination is the angle between the center of
the field of vision of the sensor and a line parallel to the ground.
S
Stopping area
Portion of the area monitored by the sensor where, if motion is detected, the system safety relays
are de-energized. If it does not correspond to the dangerous area defined in the risk assessment,
the residual risk must be calculated and additional safety measures must be introduced.
Glossary of terms
