LBK System| Instruction manual v1.3 SEP 2019 |LBK-System_instructions_en v1.3|© 2018-2019 Inxpect SpA
Error Meaning
ADC CONVERSION
ERROR
ADC conversion error in the micro-controller
Note *: see "Sensor voltage" below and "Controller voltage" below.
8.2.8 Sensor inclination errors (ACCELEROMETERERROR)
Error Meaning
PITCHANGLEERROR Sensor inclination with respect to the bracket (set through the side screws)
changed
ROLLANGLE ERROR Sensor inclination with respect to the installation surface (set through fastening
screws on the bracket) changed
ACCELEROMETERREAD
ERROR
Accelerometer reading error
8.2.9 Peripheral error (PERIPHERAL ERROR)
Error detected by diagnostics relative to the micro-controller, its internal peripherals or memories.
8.2.10 System boot (SYSTEMBOOT)
Each time LBK System starts, a "SYSTEM BOOT" event is recorded with the incremental progressive number
of the restart. The time stamp is reset to zero.
8.2.11 Sensor voltage
Screen printing Description
VIN Power supply voltage (+12 V dc)
V3.3 Internal chip power supply voltage
V1.2 Micro-controller power supply voltage
V+ Radar reference voltage
VDCDC Main chip power supply internal voltage
VOPAMP Operational amplifier voltage
VADC REF Analog-digital converter (ADC) reference voltage
8.2.12 Controller voltage
Screen printing Description
VIN Power supply voltage (+24 V dc)
V12 Relay power supply voltage
V12 sensors Sensors power supply voltage
VUSB USB port voltage
VSNS Inputs reference voltage
8.3 Cleaning and spare parts
8.3.1 Cleaning
Keep the sensor clean and free of any work residues to prevent masking and/or poor functioning of the
system.
8.3.2 Spare parts
Part Product code
Sensor LBK-S01
Controller LBK-C22
8. Maintenance and troubleshooting
