Inxpect LBK System User Manual

LBK System| Instruction manual v1.3 SEP 2019 |LBK-System_instructions_en v1.3|© 2018-2019 Inxpect SpA
9
l If the system configuration allows access to the dangerous area without detection, implement additional
safety measures (e.g. guards).
l The presence of static objects, in particular metallic objects, within the field of vision may limit the
efficiency of sensor detection. Keep the sensor field of vision unobstructed.
l The system protection level (SIL 2, PL d) must be compatible with the requirements set forth in the risk
assessment.
l Check that the temperature of the areas where the system is stored and installed is compatible with the
storage and operating temperatures indicated in the technical data of this manual.
2.1.5 WARNINGS FOR THE RESTART PREVENTION FUNCTION
l The restart prevention function is not guaranteed in blind spots. If required by the risk assessment,
implement adequate safety measures in those areas.
l Machinery restarting must be enabled only in safe conditions. The restart enable button must be installed:
o
outside of the dangerous area
o
not accessible from the dangerous area
o
in a point where the dangerous area is fully visible
2.1.6 RESPONSIBILITY
The machinery designer and system installer are responsible for the operations listed below:
l Providing adequate integration of the system's outgoing signals (both safety and auxiliary).
l Checking the monitored area of the system and validating it based on the needs of the application and
risk assessment. Following the instructions provided in this manual.
2.1.7 LIMITS
l The system cannot detect the presence of people who are immobile and not breathing or objects within
the dangerous area.
l The system does not offer protection from pieces ejected from the machinery, from radiation, and objects
falling from above.
l The machinery command must be electronically controlled.
2.2 Conformity
2.2.1 STANDARDS AND DIRECTIVES
Directives 2006/42/EC (MD - Machinery)
2014/53/EU (RED - Radio equipment)
Standards IEC/EN 62061: 2005 SIL 2
EN ISO 13849-1: 2015 PL d
EN ISO 13849-2: 2012
IEC/EN 61496-1: 2013
IEC/EN 61508: 2010 Part 1-7 SIL 2
ETSI EN 300 440 v2.1.1
ETSI EN 301 489-1 v2.2.0 (only emissions)
ETSI EN 301 489-3 v2.1.1 (only emissions)
IEC/EN 61326-3-1:2017
IEC/EN 61010-1: 2010
Note: no type of failure has been excluded during the system analysis and design phase.
2.2.2 CE
The manufacturer, Inxpect SpA, states that the LBK System type of radio equipment complies with the
