Inxpect LBK System User Manual

7. Installation and use procedures
Contents
This section includes the following topics:
7.1 Before installation 44
7.2 Install and configure LBK System 45
7.3 Validate safety functions 49
7.4 Manage the configuration 51
7.5 Other functions 52
7.1 Before installation
7.1.1 Materials required
l Two tamper-proof screws to fasten the sensors to the floor or machinery, see "Side screws specifications"
on page61.
l Cables to connect the controller to the first sensor and the sensors to one another, see "CAN bus cables
specifications" on page61.
l A micro USB cable to connect the controller to the computer.
l A termination resistor with resistance of 120 Ω for the last sensor of the CAN bus.
l A six-pointed star head screwdriver or an accessory for tamper-proof screws with button head ("Side
screws specifications" on page61).
l If necessary, to protect the sensor and to prevent reflections from generating false alarms, one Metal
protector kit (product code: 30000010) per sensor. See the instructions supplied with the kit for
installation instructions.
Note: the Metal protector kit is particularly recommended if the sensor is installed on parts that are moving, vibrating or that
are near vibrating parts.
7.1.2 Install the Inxpect Safety application
Note: if the execution process fails, it may be that the dependencies needed by the program are not installed on the computer. To
receive assistance, send an email to safety-support@inxpect.com.
1. Download the application from the website www.inxpect.com/industrial/tools and install it on the
computer.
2. Start the application.
3. Click Login and set the password.
4. Memorize the password and provide it only to people who are authorized to change the configuration.
7.1.3 Initiate LBK System
1. Calculate the position of the sensor (see "Sensor position" on page25) and the depth of the dangerous
area (see "Dangerous area calculation" on page27).
2. "Install the controller" on the next page.
3. "Define the working frequency of the sensors" on the next page.
4. "Define the area to be monitored" on the next page.
5. "Configure the auxiliary inputs and outputs" on the next page.
6. "Install sensors on the floor" on page46 or "Install the sensors on the machinery" on page47.
7. "Connect the controller to the sensors and assign the IDs" on page48.
Note: connect the sensors to the controller off-site if access to the connectors becomes difficult once they are installed.
8. "Save and print the configuration" on page48.
9. If necessary, "Install the side guards" on page48.
10. "Validate safety functions" on page49.
44
LBK System| Instruction manual v1.3 SEP 2019 |LBK-System_instructions_en v1.3|© 2018-2019 Inxpect SpA
