ENGINE MECHANICAL 6A – 135
INTER COOLER
REMOVAL AND INSTALLATION
RTW46ALF001001
Removal Steps
1. Radiator grille
2. Front bumper fascia
3. Front bumper inpact support assembly
4. Inter cooler
Installation Steps
4. Inter cooler
3. Front bumper inpact support assembly
2. Front bumper fascia
1. Radiator grille
