ENGINE MECHANICAL 6A – 37
REMOVAL AND INSTALLATION
Read this section carefully before performing any removal and installation procedure. This section gives
you important points as well as the order of operation. Be sure that you understand everything in this section before
you begin.
Removal
P1010011
1. Battery
1) Disconnect the battery cable and the grounding cable
from the battery terminals.
2) Remove the battery clamp. Take care not to
accidentally short the battery with the wrench or some
other tool.
3) Remove the battery.
4) Disconnect the battery cable at the starter motor and
the ground cable at the cylinder body.
2. Engine Hood
Apply setting marks to the engine hood and the engine
hood hinges before removing the engine hood. This will
facilitate reinstallation of the engine hood to its original
position.
3. Supporting the Vehicle
1) Jack up the vehicle.
2) Place chassis stands at the front and the rear of the
vehicle.
4. Under cover (for 4x4 model)
5. Rear propeller shaft
1) Remove the propeller shaft flange yoke at the rear
differential.
2) Remove the center bearing retainer bolts.
3) Remove the propeller shaft together with the center
bearing from the transmission mainshaft spline.
F06R300006
P1010002
