6A – 8 ENGINE MECHANICAL
TORQUE SPECIFICATION
STANDARD BOLTS
The torque values given in the following table should be applied whenever a particular torque is not specified.
N·m (kg·m/lb·ft)
8.8
4.8 (4T) (7T)
Refined
Non-Refined
9.8 (9T)
Strength
Class
Bolt
Identification
Bolt
Diameter ×
Pitch (mm)
M 6 ×
××
× 1.0
M 8 ×
××
× 1.25
M 10 ×
××
× 1.25
M 12 ×
××
× 1.25
M 14 ×
××
× 1.5
M 16 ×
××
× 1.5
M 18 ×
××
× 1.5
M 20 ×
××
× 1.5
M 22 ×
××
× 1.5
M 24 ×
××
× 2.0
* M 10 ×
××
× 1.5
* M 12 ×
××
× 1.5
* M 14 ×
××
× 2.0
* M 16 ×
××
× 2.0
5.88 ± 1.96
(0.60 ± 0.20/4.33 ± 1.44)
12.74 ± 4.90
(1.30 ± 0.50/9.40 ± 3.62)
27.44 ± 6.86
(2.80 ± 0.70/20.25 ± 5.06)
61.25 ± 12.25
(6.25 ± 1.25/45.21 ± 9.04)
95.55 ± 19.11
(9.75 ±1.95/70.52 ± 14.10)
130.34 ± 26.46
(13.30 ± 2.70/96.20 ± 19.53)
188.16 ± 37.24
(19.20 ± 3.80/138.87 ± 27.49)
257.74 ± 51.94
(26.30 ± 5.30/190.23 ± 38.33)
332.22 ± 81.34
(33.90 ± 8.30/245.20 ± 60.03)
448.84 ± 90.16
(45.80 ± 9.20/331.27 ± 66.54)
26.46 ± 6.86
(2.70 ± 0.70/19.53 ± 5.06)
56.84 ± 11.76
(5.80 ± 1.20/41.95 ± 8.68)
89.18 ± 17.64
(9.10 ± 1.80/65.82 ± 13.02)
124.46 ± 24.50
(12.70 ± 2.50/91.86 ± 18.08)
7.35 ± 2.45
(0.75 ± 0.25/5.43 ± 1.80)
17.15 ± 5.39
(1.75 ± 0.55/12.66 ± 4.00)
36.75 ± 9.31
(3.75 ± 0.95/27.12 ± 6.87)
75.95 ± 15.19
(7.75 ± 1.55/56.06 ± 11.21)
116.13 ± 23.03
(11.85 ± 2.35/85.71 ± 17.00)
169.54 ± 34.30
(17.30 ± 3.50/125.13 ± 25.32)
244.02 ± 49.00
(24.90 ± 5.00/180.10 ± 36.17)
337.12 ± 67.62
(34.40 ± 6.90/248.82 ± 49.41)
453.25 ± 90.65
(46.25 ± 9.25/334.53 ± 66.91)
570.36 ± 140.14
(58.20 ± 14.30/420.96 ± 103.43)
36.26 ± 8.82
(3.70 ± 0.90/26.76 ± 6.50)
70.56 ± 13.72
(7.20 ± 1.40/52.08 ± 10.13)
109.76 ± 21.56
(11.20 ± 2.20/81.01 ± 15.91)
161.70 ± 32.34
(16.50 ± 3.30/119.34 ± 23.87)
-
23.52 ± 6.86
(2.40 ± 0.70/17.36 ± 5.06)
49.98 ± 12.74
(5.10 ± 1.30/36.89 ± 9.40)
94.57 ± 19.11
(9.65 ± 1.95/69.80 ± 14.10)
142.10 ± 28.42
(14.50 ± 2.90/104.88 ± 21.00)
199.92 ± 40.18
(20.40 ± 4.10/147.55 ± 29.66)
287.14 ± 57.82
(29.30 ± 5.90/211.93 ± 42.67)
395.92 ± 79.38
(40.40 ± 8.10/292.21 ± 58.59)
530.18 ± 105.84
(54.10 ± 10.80/391.30 ± 78.12)
691.88 ± 138.18
(70.60 ± 14.10/510.65 ± 101.99)
48.02 ± 11.76
(4.90 ± 1.20/35.44 ±8.68)
89.18 ± 17.64
(9.10 ± 1.80/65.82 ± 13.02)
133.28 ± 26.46
(13.60 ± 2.70/98.37 ± 19.53)
191.10 ± 38.22
(19.50 ± 3.90/141.04 ± 28.21)
An asterisk (*) indicates that the bolts are used for female threaded parts that are made of soft materials
such as casting. Those shown in parentheses in the strength class indicate the classification by the old
standard.
FLARE NUTS N·m (kg·m/lb·ft)
Pipe diameter mm
(in)
Torque
Pipe diameter mm
(in)
Torque
4.76 (0.187)
6.35 (0.250)
8.00 (0.315)
15.2 ± 2.45(1.55 ±0.25/11.2 ± 1.8)
26.48 ± 2.94(2.70 ± 0.30/19.5 ± 2.1)
44.14 ± 4.90(4.50 ± 0.50/32.5 ± 3.6)
10.00 (0.394)
12.00 (0.472)
15.00 (0.591)
53.95 ± 4.90(5.50 ± 0.5 /39.7 ± 3.6)
88.29 ± 9.80(9.00 ± 1.0/65.0 ± 7.2)
105.45 ± 12.26(10.75 ± 1.25/77.7 ± 9.0)
