Jacobsen Eclipse 322 Repair Manual

4-26 4222983 Second Edition
ELECTRICAL
4
Electrical Schematic
Continued
Figure 4-17
PDU PDU
GC1
1L Blk
12V Switched Power 12V Switched Power 12V Switched Power
CAN Shield
CAN Low
CAN High
20 Wht/Blu 20 Wht/Blu
Shield1L
Blk
92E
Grn
91E
Yel
Ground
J100-4
CAN
Shield
J100-9
CAN
Low
J100-8
CAN
High
J100-5
A15
Overvoltage
Limit
Monitor
(OLM)
107 Org/Grn
102 Brn
105 Grn/Blk
106 Yel/Wht
101 Red
101A Red
J100-1 48V Input
J102 (Connects to TCU +48V B+ Terminal)
J100-2 48V Input
J100-3 Resistor Output 1
J100-12 Resistor Output 2
J100-11 Resistor Output 3
J100-10 Resistor Output 4
G4
48V
Generator
+48V
To
PDU
Stud 3
Permanent
Magnet
Generator
Diode Blocks
150A
Shunt
Resistor
28 Red
13 Brn
Org
Org
95 Blk
94 Red
Pur
Pur
B6
Rectifier
Temperature
Sensor
B5
Permanent
Magnet
Generator
Temperature
Sensor
G
013 Blk
12V Switched Power Circuit
TN1664
