jcb 3CX Service Manual

3 - 2
Pre-start Cold Checks Operation 10 50 †100 500 1000 2000
Service Points and Fluid Levels Hr Hr Hr Hr Hr Hr
Hydraulic Oil Cooler - Clean
!!!
Hydraulic Oil Strainer - Clean
!
Hydraulic Tank Filler Cap (with integral filter) - Change
!
Hydraulic Pump Drive Shaft - Examine/Grease
!! !!
BRAKES
Brake System Fluid Level - Check
!!! ! ! !
Brake System Fluid ∃ - Change
!
Parking Brake - Check and Adjust
!! !!
ELECTRICS
Battery Electrolyte Level (if applicable) - Check
!!!
Wiring for Chaffing/Routing - Check
!! ! ! !
Battery Terminals for Condition and Tightness - Check
!! !!
BODYWORK AND CAB
All Pins and Bushes - Check and Grease
!!! ! ! !
Door/Window Hinges - Lubricate
!!!
All Cables - Lubricate
!!!
Cab Heater Filter # - Clean/Change
!!!
Extending Dipper - Adjust/Grease
!! ! ! !
Hydraclamp ∃ - Check and Adjust
!! !!
Door - Fit and Catches - Check
!! !!
Cab Seat - Operation - Check
!! !!
Front Mudguards - Security (if fitted) - Check
!!
Windscreen Washer Fluid Level - Check
!!! ! ! !
Boom Lock Engagement - Check
!!! ! ! !
Condition of Paintwork - Check
!! !!
Stabiliser Legs (Sideshift) - Check/Adjust
!! ! ! !
Machine Generally ∃ - Check and Clean
!!! ! ! !
Power Sideshift Wear Pads - Grease
!!! ! ! !
Power Sideshift Wear Pads - Check
!!
Power Sideshift Chain - Lubricate
!! ! ! !
Power Sideshift Chain Tension - Check/Adjust
!! !!
ATTACHMENTS
6-in-1 Clam Shovel - Grease
!!! ! ! !
Backhoe & Loader Quick Hitch - Grease
!!! ! ! !
Functional Test Operation 10 50 †100 500 1000 2000
and Final Inspection Hr Hr Hr Hr Hr Hr
ENGINE
Idle Speed ∃ - Check and Adjust
!! !!
Stall Speed ∃ - Check
!! !!
Maximum No-Load Speed ∃ - Check and Adjust
!! !!
Exhaust Smoke (excessive) - Check
!! ! ! !
Exhaust System Security ∃ - Check
!! !!
Air Inlet System Security - Check
!! !!
Throttle System and Control Cable ∃ - Check
!! ! !
TRANSMISSION, AXLES AND STEERING
Steer Modes - Operation/Phasing - Check
!!! ! ! !
2WD/4WD Selection - Check
!! !!
Wheel Nuts Torque - Check
!!! ! ! !
Forward/Reverse and Gear Change - Operation - Check
!! !!
Section 3 Routine Maintenance
9803/3280
Section 3
3 - 2
Issue 1
Service Schedules
