XP9303 Transmitter Features (Internal)
Control Stick Tension Adjustment
G11
Remove the six transmitter back screws as shown on the
previous page. Remove the transmitter back, being careful
not to cause damage to any components.
Adjust each screw for desired tension (counter-clockwise
to loosen stick feel; clockwise to tighten stick feel). When
adjusting the throttle ratchet tension, make sure that
the adjusting screw does not touch the PC board after
adjustment is complete.
ELEVATOR TENSION SCREW
AILERON TENSION SCREW
THROTTLE TENSION SCREW
RUDDER TENSION SCREW
