To Activate Flight Modes
A8
1. From SYSTEM M. highlight and select Devic. SEL
using the Selector.
2. Using the Selector, highlight and select INH under
FLIGHT MODE. When selected, two options appear:
AUX2 SW and FLAP SW. Highlight and select the
switch that is to be used to select between Flight
Modes while flying. The example below shows that the
FLAP switch has been selected.
Once Flight Modes have been activated, 2 new parameters
appear on the display: TRIM:COM and D/R:SW.
Once one of the 3-position switches is selected, Flight
Mode 0 (FM0) is in effect when the switch is in the
upper position, Flight Mode 1 (FM1) is in effect when
the switch is in the middle position and Flight Mode
2 (FM2) is in effect when the switch is moved to the
lowest position.
