FM0-FM2 (Flap System)
A27
If Flight Modes have been activated in the Devic. SEL
function of the SYSTEM Menu then FM0, FM1 and FM2
will appear along the right side of the Flap System display
to represent the 3 Flight Modes. Each of the Flight Modes
can be assigned one of the Flap values (NORM, Mid, or
Land), so when that Flight Mode is selected during flight,
the Flaps deploy to that position. SW is also an option.
When SW is selected for a Flight Mode, flap operation is
controlled by the Flap switch when in that Flight Mode.
If Flight Modes have not been activated, skip this portion
of the Flap System.
1. For each Flight Mode, highlight and select FM0-FM2
and select either a flap position (NORM, Mid, Land)
that the flaps are to assume when in that Flight Mode,
or select SW if the Flap switch is to control the flaps
when in that Flight Mode.
The example above shows that Flight Mode 0 (FM0) is
set to SW which means that the Flap switch will be used
to control flaps when in this Flight Mode. FM1 is set to
Mid, resulting in the flaps deflecting to the Mid position
when Flight Mode 1 is selected and FM2 is set to Land,
indicating that the flaps will deploy to the Land position
when Flight Mode 2 is selected.
