TRAINER – TRAINER SYSTEM
XP9303 USED AS MASTER (INSTRUCTOR) – (Trainer System)
A44
The XP9303 contains a Trainer System that allows
the instructor to transfer some or all of the primary
flight control functions (Throttle, Aileron, Elevator and
Rudder) to the student. It also allows for indicating if
the transmitter (TX) is to be the Master (controlled by
the instructor) or Slave (controlled by the student). The
Snap Roll button is used to transfer control to the student
when the XP9303 is being used as the Master/Instructor
transmitter.
All Dual rates and Exponential settings in the Master TX
are transferred to the Slave TX. The Slave TX battery must
be charged.
1. Connect the Trainer cord between the Master and
Slave transmitters. Turn the power on to the Master
transmitter (the Slave TX remains powered off and can
even have the module removed).
2. Make sure the Slave TX is in the PPM/FM modulation
mode. See MODULAT in the SYSTEM Menu if the
Slave TX is a XP9303 or refer to the owners manual if
the TX is not a XP9303.
3. Highlight and select Trainer in the FUNC.LIST to
obtain the Trainer Display.
1. If the XP9303 is being used as the Master TX (the TX
operated by the instructor), select the channel(s) that
are to be operated by the Slave TX (TX operated by the
student) when the trainer switch is depressed.
When all channel selectors are in the MAST position,
NORMAL appears on the display and all 4 channels are
transferred to the student when the trainer switch
is depressed.
If only certain channels are to be transferred to the
student, highlight and select the channels that are to be
transferred, moving the indicator for these channels to
the SLAV position for these channels. When less than all
channels are selected as SLAV, PROGRAM T appears
on the display indicating that the Trainer System has been
programmed to transfer only selected channels.
The XP9303 is now ready to be used as the Master or
instructor TX. Depress the Snap Roll button to transfer
control to the student. Control will remain transferred until
the Snap Roll button is released.
