TRVL ADJ. – TRAVEL ADJUST
A19
Travel Adjust, sometimes referred to as ATV, is used to
adjust how far a servo travels in each direction. After the
linkages have been installed and attached to the servos,
adjust the amount of servo travel in each direction.
For more information on Servo Travel and Mechanical
Advantage, please refer to the
Sub Trim Usage and
Mechanical Advantage
article contained in the Glossary.
1. Highlight and select TRVL ADJ. in the FUNC.LIST to
obtain the Travel Adjust display.
2. Use the Selector to highlight and select each channel
and adjust the travel in each direction by rotating the
Selector. The direction of travel is changed by moving
the stick/switch/lever back and forth.
[TRVL ADJ.]
THRO L100% R100%� GEAR +100% -100%
AILE L100% R100%� FLAP U100% D100%
ELEV D100% U100%� AUX2 +100% -100%
RUDD L100% R100%� AUX3 +100% -100%
� � � AUX4 +100% -100%
