WING Parameter – (Wing Type)
A13
1. Highlight and select Wing TYPE in the SYSTEM
Menu using the Selector.
2. If only the Aileron channel is to control both Ailerons,
either with a single servo or with 2 servos connected
together via a “Y” harness, then leave the Wing
3. If 2 channels are to be used to control the Ailerons and
the aircraft does not have separate flaps, highlight and
select Wing with the Selector and then highlight
and select FLAPERON as the wing type. Plug the
right Aileron into the Aileron channel (Ch2) and plug
the left Aileron servo into the FLAP or AUX1 channel
(Ch6) of the RX. Continue with V-tail below.
parameter set to the default of NORMAL and plug the
Aileron servo into the Aileron channel (Ch2) of the RX.
Also use NORMAL if the aircraft has flaps that are
separate from the ailerons.
Note: If the Ailerons are not going to actually be
used as flaps, inhibit the FLAP Switch and FLAP
TRIM in the Devic.SEL function in the SYSTEM
Menu. This will eliminate having a severe out-of-
trim condition if the FLAP Switch or FLAP TRIM is
accidentally moved.
4. If the aircraft is a Delta wing configuration, highlight
and select Wing using the Selector and then
highlight and select DELTA as the wing type. Plug the
right Aileron into the Aileron channel (Ch2) and plug
the left Aileron into the Elevator channel (Ch3) of the
RX. Continue with V-tail below.
