JUKI DNU-1541 Engineer's Manual

− 48 −
Pin No. Relay cable (asm.) : 21443957
1 GND (Yellow)
2 DL switch 1 (Red)
3 DL LED (–) (Yellow), DL (–) (Black)
4
5 DL switch 2 (Orange)
6 DL switch (Orange)
7
8 LED (+) (Blue)
9
10
11
12
13 ABT switch (Red)
14
15
™ 15-pin connector
Pin No. Relay cable (asm.) : 21443957 Relay cable (asm.) : 21414958
1 AK (–) (Black) AK (–) (Black)
2 AK (+) (White) AK (+) (White)
™ 2-pin connector
Pin No. Relay cable (asm.) : 21443957
1 Thread trimmer (–) (Red)
2 2P LED (–) (Black)
3 Needle UP switch (Yellow)
4 2P switch (White)
5 BT switch (Brown)
6 BT (–) (Blue)
7 Tension release (–) (Yellow)
8 Thread trimmer (+) (Orange)
9
10 Earth (Green/Yellow)
11
12 GND (Red)
13 BT (+) (Green)
14 Tension release (+) (Blue)
(3) Connector coming from the relay cable (Inserting side to the control box)
™ 14-pin connector

JUKI DNU-1541 Specifications

General

Machine Type	Industrial Sewing Machine
Max Stitch Length	9mm
Needle Bar Stroke	36.5mm
Presser Foot Lift	16mm (by knee), 9mm (by hand)
Needle	DP×17 (#14) #11-#18
Lubrication	Automatic
Weight	34kg (head only)
Stitch Type	Lockstitch
Stitch Length	9mm
Max Sewing Speed	2, 500 stitches per minute
Type	Lockstitch
Application	Heavy-Weight Materials
Maximum Sewing Speed	2, 500 stitches per minute
Bobbin	Large bobbin
Motor	Servo Motor (optional)
Hook Type	Horizontal-axis full-rotary double-capacity hook
