Hydraulic system: The lifting and lowering functions are controlled by means of ope-

rating keys. When the lifting function is actuated, the pump unit will start up, delivering

hydraulic oil from the oil reservoir to the lifting cylinder. A hydraulic accumulator and

a flow control valve allow attenuated lifting and lowering.

Electrical system: 24 V two-wire system. As a standard feature, the truck is equip-

ped with an electronic drive current control system.

2.2 Technical description - load lifting device

Lifting device: Single-stage hoist frame (25), welded model. The inner mast with the

driver stand platform (15) and the fork (29) runs on roller bearings to keep the friction

loss and the power consumption as low as possible. Lifting occurs by extending hy-

draulic cylinders. When the auxiliary lifting unit (o) is used, the fork (29) is lifted via a

centred lifting cylinder by means of a guide chain.

The truck can be equipped with a two-stage hoist frame.

3 Technical data - standard version

Technical data according to VDI 2198.

Technical data are subject to alteration and extension in scope.

3.1 Performance data

Designation

Q Rated capacity 1000 kg

C Load centre distance 600 mm

Travelling speed with / without rated load 9.5 / 10.5 km/h
