Jungheinrich ECP 100-3 User Manual

0803.GB
E 2
2 Description of the operating controls and indicators
Item Operating control or indica-
tor
Function
1 Controller t Controls the direction of travel as well as
the travelling speed.
2 Key “Two-hand operation” o Releases the lifting and driving functions
when pressed (in the rail guidance mode
with aisle recognition).
3 Steering wheel t Steers the truck.
4 Information- and service-
display (LISA)
t Displays essential driving parameters, lif-
ting parameters, warning signals, operating
errors and service data (refer to section 5).
5 Clipboard t For DIN A4 formats.
6 Master switch
(emergency stop)
t The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
7 Key “Lowering” t Driver standing platform.
8 Key “Lifting” t Driver standing platform.
9 Key switch with key t Switches the control current on and off.
When the key is removed from the key
switch, the truck cannot be operated by un-
authorised persons
10 Key “Warning signal”
(horn)
t Gives an audible warning signal.
11 2nd Master switch
(emergency stop)
o Optional equipment “Pedestrian-controlled
operation”:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
13 Key “Lifting” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted together with the driver
standing platform.
13 Key “Lowering” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted together with the driver
standing platform.
t = Standard equipment o = Optional equipment
0803.GB
E 2
2 Description of the operating controls and indicators
Item Operating control or indica-
tor
Function
1 Controller t Controls the direction of travel as well as
the travelling speed.
2 Key “Two-hand operation” o Releases the lifting and driving functions
when pressed (in the rail guidance mode
with aisle recognition).
3 Steering wheel t Steers the truck.
4 Information- and service-
display (LISA)
t Displays essential driving parameters, lif-
ting parameters, warning signals, operating
errors and service data (refer to section 5).
5 Clipboard t For DIN A4 formats.
6 Master switch
(emergency stop)
t The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
7 Key “Lowering” t Driver standing platform.
8 Key “Lifting” t Driver standing platform.
9 Key switch with key t Switches the control current on and off.
When the key is removed from the key
switch, the truck cannot be operated by un-
authorised persons
10 Key “Warning signal”
(horn)
t Gives an audible warning signal.
11 2nd Master switch
(emergency stop)
o Optional equipment “Pedestrian-controlled
operation”:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
13 Key “Lifting” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted together with the driver
standing platform.
13 Key “Lowering” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted together with the driver
standing platform.
t = Standard equipment o = Optional equipment
