4.1 Truck identification plate
A
In the event of queries relating to the truck or spare part orders, please state the serial
No. (49) of the truck.
4.2 Load diagram, capacity / load centre / lifting height
The load diagram (41) shows the capacity Q of the truck in kg with the hoist frame in
the vertical position. The diagram indicates the maximum capacity at a specific load
centre D (in mm) and at the desired lifting height H (in mm) in the form of a table.
Example showing the determination of the max. capacity:
At a load centre D of 600 mm and a maximum lifting height H of 1000 mm, the maxi-
mum capacity Q is 1000 kg.
Item Designation Item Designation
48 Type 55 Drive power in kW
49 Serial No. 56 Customer no.
50 Rated capacity in kg 57 Min./max. battery weight in kg
51 Battery: Voltage V
Ampere hours Ah
58 Empty weight without battery in kg
52 Manufacturer 59 Year of manufacture
53 Order no. 60 Manufacturer logo
54 Load centre distance in mm
48
49
50
51
52
53
55
59
58
57
56
54
60








0201.GB
B 10
4.1 Truck identification plate
A
In the event of queries relating to the truck or spare part orders, please state the serial
No. (49) of the truck.
4.2 Load diagram, capacity / load centre / lifting height
The load diagram (41) shows the capacity Q of the truck in kg with the hoist frame in
the vertical position. The diagram indicates the maximum capacity at a specific load
centre D (in mm) and at the desired lifting height H (in mm) in the form of a table.
Example showing the determination of the max. capacity:
At a load centre D of 600 mm and a maximum lifting height H of 1000 mm, the maxi-
mum capacity Q is 1000 kg.
Item Designation Item Designation
48 Type 55 Drive power in kW
49 Serial No. 56 Customer no.
50 Rated capacity in kg 57 Min./max. battery weight in kg
51 Battery: Voltage V
Ampere hours Ah
58 Empty weight without battery in kg
52 Manufacturer 59 Year of manufacture
53 Order no. 60 Manufacturer logo
54 Load centre distance in mm
48
49
50
51
52
53
55
59
58
57
56
54
60








