105
11.14 EN
6.5 Emergency Disconnect
CAUTION!
Applying maximum braking can result in accidents
Applying the Emergency Disconnect switch during travel will cause the truck to
decelerate to a halt at maximum force. This may cause the load to slide off the load
handler. There is a higher risk of accidents and injury.
X
Do not use the Emergency Disconnect switch as a service brake.
X
Use the Emergency Disconnect switch during travel only in emergencies.
Applying the Emergency Disconnect
Procedure
• Press the Emergency Disconnect switch (89).
All electrical travel, steering and hydraulic functions are
cut out. The truck brakes to a halt at maximum brake
force.
6.5.1 Battery Isolator
Procedure
• Move the battery isolator (182) to position "1". All
electrical functions are enabled.
• Move the battery isolator (182) to position "0" and
remove it as necessary: All electrical functions are
deactivated.
