3.4 Mast versions
Z All dimensions in mm.
Mast chart
V D I 3 5 9 6
Description
Lift h
3
Free lift
h
2
Retracted
height h
1
Extended
height h
4
Weight
(kg)
660/670 660/670
ZT
3600 0 2710 4510 2080
4000 0 2910 4910 2140
4500 0 3160 5410 2240
5000 0 3410 5910 2335
5500 0 3660 6410 2460
6000 0 3910 6910 2585
6500 0 4160 7410 2735
ZZ
3600 1800 2875 4675 2278
4000 2000 3075 5075 2350
4500 2250 3325 5675 2422
5000 2500 3575 6075 2542
5500 2750 3825 6575 2652
6000 3000 4075 7075 2772
6500 3300 4325 7575 2892
DZ
4500 1500 2585 5585 2671
5000 1667 2752 6086 2754
5500 1833 2918 6586 2837
6000 2000 3085 7086 2920
6500 2167 3252 7586 3045
7000 2333 3418 8086 3191
7500 2500 3585 8586 3295
8000 2667 3752 9086 3397
