22
PRODUCT FEATURES
2.3 Product features
This instruction manual describes the power circuits of the following devices:
Unit type: Drive converter
Series: COMBIVERT S6
Power range: 4...7.5 kW / 400 V
Housing: 4
The COMBIVERT S6 is characterized by the following features:
•
For asynchronous, synchronous, IPM or synchronous reluctance motors
• With encoder or encoderless SCL and ASCL for accurate speed control
• Motor temperature monitoring PTC, KTY or PT1000
• Two-channel multi-encoder interface
• Integrated braking transistor
• Integrated brake control
• Integrated safety functionality
• Basic function STO in the compact version
• Additional high level safety in the application version
•
Real-time Ethernet interfaces
•
CAN
•
RS232/485 for diagnosis or display
• Book format for space-saving control cabinet construction
• Direct mains connection for 230 V and 400 V mains, alternatively also DC input
260…750 V
• Lowleakagecurrentmainslter(<5mA)integrated,optionalwithoutlter
• High overload for best dynamics (250 % / 3s, 200 % / 60s)
• Supports existing machine concepts with 8 digital and 2 analog inputs, 2 digital
outputs + 1 relay and 1 analog output 0…10 V
Due to the wide voltage range, the 3-phase 400V devices can also be operated
on 230V applications. Further information can be found in chapter „UL Marking“.
