Table 6-4
Pulse board parts list
Circuit designation Description
Keithley
Part No.
C801, 803, 805, 807, 809, 810-
824
CAP, 220U, 20%, 160V, ALUM C-584-220
C802, C804 CAP, 2200U, 20%, 50V, ALUM C-586-2200
J1 CONN, MALE 3 PIN CS-612-1
J1029 HEADER CS-715-5
R1, R4 RESISTOR, WIREWOUND R-257-100
R6, R7, R9, R10 RESISTOR, WIREWOUND R-34-10
R2, R3 RESISTOR R-496-1K
R11, R12, R13, R14 RES, 100K, 1%, 1/2W, METAL FILM R-94-100K
R5, R8 RES, 7.15K, 1%, 1/2W, METAL FILM R-94-7.15K
CR1, CR2 DIODE, SILICON, IN4148 RF-28
K1, K2 RELAY RL-218
6-20 Replaceable Parts
