1-10 Performance Verification
2. Select the multimeter DC volts function.
3. Set the Model 2430 to both source and measure voltage by pressing the SOURCE V and
MEAS V keys, and make sure the source output is turned on.
4. Verify output voltage accuracy for each of the voltages listed in Table 1-4. For each test
point:
• Select the correct source range.
• Set the Model 2430 output voltage to the indicated value as measured by the digital
multimeter.
• Verify that the Model 2430 voltage reading is within the limits given in the table.
NOTE It may not be possible to set the voltage source to the specified value. Use the closest
possible setting, and modify reading limits accordingly.
5. Repeat the procedure for negative source voltages with the same magnitudes as those
listed in Table 1-4.
6. Repeat the entire procedure using the rear panel INPUT/OUTPUT jacks. Be sure to
select the rear panel jacks with the front panel TERMINALS key.
Table 1-4
Voltage measurement accuracy limits
Model 2430 source
and measure range
1
Source voltage
2
Model 2430 voltage reading
limits (1 year, 18°C to 28°C)
200mV
2V
20V
100V
200.000mV
2.00000V
20.0000V
100.000V
199.676 to 200.324mV
1.99946 to 2.00054V
19.9960 to 20.0040V
99.980 to 100.020V
1. Measure range coupled to source range when simultaneously sourcing and measuring voltage.
2. As measured by multimeter. Use closest possible value and modify reading limits accordingly.
Output current accuracy
Follow the steps below to verify that Model 2430 output current accuracy is within specified
limits. The test involves setting the output current to each full-range value and measuring the
currents with a precision digital multimeter.
10μA to 1A range accuracy
1. With the power off, connect the digital multimeter to the Model 2430 INPUT/OUTPUT
jacks, as shown in Figure 1-2.
