Replaceable Parts 6-13
Table 6-2
Digital board parts list
Circuit designation Description
Keithley
Part No.
BT1 BATTERY, 3V BA-46
C1, 3, 11-14, 16, 17, 20, 22, 23, 25,
26, 30, 77
CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C103 CAP, 100UF, 20%, 10V, ALUM ELEC C-483-100
C104 CAP, 10UF, 20%, 63V, ALUM ELEC C-403-10
C107, C110 CAP, 82U, 20%, 450V, ALUMINUM C-554-82
C113, C115, C117, C119 CAP, 10U, 20%, 35V, TANTALUM C-551-10
C114 CAP, 220UF, ±20%, 50V, ALUM ELEC C-507-220
C116 CAP, 100UF, 20%, 16V, ALUM ELEC C-530-100
C120 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C121 CAP, 390P, 10%, 100V, CERAMIC C-451-390P
C122, C125 CAP, 0.47U, 20%, 25V C-520-.47
C123 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C126 CAP, 100P, 10%, 100V, CERAMIC C-451-100P
C127, C128, C129, C130, C211 CAP, 100P, 10%, 100V, CERAMIC C-451-100P
C131 CAPACITOR C-570-470
C15, C37, C204, C205, C206, C207,
C208, C209
CAP, 0.01U, 10%, 500V, CERAMIC C-497-.01
C19, C69, C75, C85, C92, C200,
C201
CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C2, 4, 8, 24, 44, 56, 61, 76, 78, 80, 82,
87, 88, 89
CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C202 CAP, 47PF, 10%, 100V, CERAMIC C-451-47P
C203 CAP, 1000PF, 10%, 50V, MONO
CERAMIC
C-452-1000P
C24, C96 CAP, 0.1U, 20%, 250V, FILM C-553-.1
C28 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C31, C50, C210 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C32, C36 CAP, 1UF, 20%, 50V, CERAMIC C-519-1
C33, C63, C74, C93 CAP, 0.047U, 10%, 50V, CERAMIC C-491-.047
C35 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C39, 41, 42, 49, 59, 66-68, 79, 81, 83 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
