Configuration menus
The configuration menus are summarized in Table 1-4, along with the reference for each main
selection. There are two ways to make selections:
• Press CONFIG, then navigate to the desired submenu.
• Press CONFIG, then press the associated key. For example, pressing CONFIG followed by
REL takes you directly to the Relative menu.
Table 1-4
Configuration menus
Menu selections Shortcut Description Reference
CHANNEL-A
SRC
MEAS
LIMIT
SPEED
REL
FILT
OUTPUT
SRC
MEAS
LIMIT
SPEED
REL
FILTER
OUTPUT
Configure Channel A:
V-source sense, low range; I-source low range.
V and I-Measure sense, low range; auto zero.
V-source and I-source compliance limits.
Measurement speed (NPLC).
Set relative values.
Control digital filter.
Set off-state, control digital I/O.
Section 4
Section 4
Section 4
Section 6
Section 6
Section 6
Section 3
Section 10
CHANNEL-B
SRC
MEAS
LIMIT
SPEED
REL
FILT
OUTPUT
SRC
MEAS
LIMIT
SPEED
REL
FILTER
OUTPUT
Configure Channel B:
V-source sense, low range; I-source low range.
V and I-Measure sense, low range; auto zero.
V-source and I-source compliance limits.
Measurement speed (NPLC).
Set relative values.
Control digital filter.
Set off-state, control digital I/O.
Section 4
Section 4
Section 4
Section 6
Section 6
Section 6
Section 3
Section 10
COMMON
TRIG
STORE
TRIG
STORE
Configure common functions:
Set trigger in, count, interval, and delay.
Set buffer count and destination.
Section 9
Section 7
Interface selection
The following summarizes basic interface selection for the Series 2600. Details on the interfaces,
including configuration, are provided in
Section 11. Use the editing controls for "Menu navigation"
described earlier in this section to select and configure the interface.
LINE-FREQ
AUTO
50Hz
60Hz
Configure the line frequency.
Automatically selects the line frequency.
Section 1
SYSTEM-INFO
FIRMWARE
SERIAL#
CAL
Displays the system information.
Displays the version of firmware installed.
Displays the serial number of the unit.
Displays the last calibration date.
Section 1
Menu selection Description Reference
To Next Page
