Series 2600 System SourceMeter® Instruments Reference Manual Section 1: Getting Started

Table 1-5

Default settings

Setting Default

A/D controls:

Auto-zero Auto

Line frequency Auto (firmware version 1.2.0 or higher)

No effect (firmware versions lower than 1.2.0)

Beeper On

Data store No effect

Digital output:

Output value No effect

Write protect No effect

Digits 5-1/2

Display mode (Models 2602/2612/2636) Dual-channel

Filter: Off

Averaging type Repeat

Count 1

GPIB address No effect

Limit value:

Current limit 1A Models (2601/2602/2611/2612)

100mA Models (2635/2636)

Voltage limit 20V Models (2635/2636)

40V Models (2601/2602)

200V Models (2611/2612)

Measure:

Function Voltage

I-meter range 100mA

V-meter range 100mV Models (2601/2602)

200mV Models (2611/2612/2635/2636)

Output Off

Off state Normal

Rel Off

Current value 0.0pA

Voltage value 0mV

Ohms value 0mΩ

Watts value 0mW

RS-232 No effect
