Keithley 2601 Reference Manual

2-22 Return to Section Topics 2600S-901-01 Rev. C / January 2008
Section 2: TSP Programming Series 2600 System SourceMeter® Instruments Reference Manual
Figure 2-14
Run dialog box (Script Attributes tab)
Launching a script
After checking and/or changing a launch configuration, the script is launched from the Run dialog
box by clicking the Run button shown in
Figure 2-13.
A script can be relaunched directly from the toolbar located at the top of the Test Script Builder.
Figure 2-15 explains how to relaunch a script from the toolbar.
Figure 2-15
Relaunching a script from the Test Script Builder toolbar
Click Run and click
Run Last Launched
in the drop-down menu.
OR
Click and then click the
script in the drop-down
menu.
Click
OR
