 Enclose the contents of the channel list in either single (') or double (") quotes, but the
quote style must match.
 Use a comma or semicolon to separate the channel list or channel patterns.
 The string may contain a single channel, channel pattern or analog backplane relay as
well as multiple ones that are indicated by a range or comma separated.
 Use a colon to specify a range of channels. Example:
channel.getbackplane("1001:1003") responds with the range of Slot 1 channels from 1 to
3.
Although a parameter string may be valid, the command that calls it will determine the string's
ultimate validity. For example, only channels have a pole setting (channel patterns do not). If a
channel pattern is passed to the poles setting command, an error would be generated.
Channel patterns may be included as a <ch_list> parameter.
<ch_list> queries
For queries that return a channel list parameter, a channel configured for 4-pole operations will
indicate the paired channel in parenthesis. For example, Channel 3003 on a 60-channel card is
configured for 4-pole, then sending:
channel.close('3003')
print(channel.getclose('slot3')  3003(3033)
NOTE In the above examples output the paired channel associated with 3003 is 3033 and
is in included in parenthesis.
Channel operation
The channel number is displayed on the Series 3700's front panel. For a 4-wire function (in other
words, Ω4), the paired channel is internally connected to DMM sense, but not displayed. When
triggered, the DMM performs a measurement and displays it on the Series 3700.
When a measurement channel is closed (measurement channel meaning that a function other
than 'no function' is associated with the channel), the input backplane isolation channel also
closes to connect the channel to DMM input. For a 4-wire function, the paired channel and the
sense backplane isolation channel also close to make the sense connections to the DMM.
