Keithley 6517A Getting Started Guide

Model 6517A Getting Started Manual Front Panel Operation 1-15
Figure 1-5
Resistance measurements
Red
Black
6517A
Shield
R
X
Measured
Resistance
LO connected
to shield
CAUTION:FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME
CAUTION:FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME
WARNING:NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PER
237-ALG-2
Cable
INPUT
250V PEAK
COMMON
TRIGGER
LINK
IN OUT
!
PREAMP OUT
250V PEAK
V SOURCE
LO HI
Note: V-Source low internally
connected to electrometer low.
A. Generic connections
Model 6517A
Note: Set fixture mode switch to
picoammeter operation.
7078-TRX-3 Triax Cable
8607 Banana Plug Cables
8002-ILC-3 Interlock Cable
Warning: Connect of fixture to safety earth
ground using safety ground wire
(supplied with 8002A test fixture).
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
INPUT
250V PEAK
COMMON
OUT
!
LINE RATING
90-134VAC
180-250VAC
50, 60, 400HZ
55VA MAX
IE
(CHANGE
WITH FRO
N
PREAMP OUT
250V PEAK
V SOURCE
LO HI
8002A HIGH RESISTANCE TEST FIXTURE
INTERLOCK
!
B. Connections using 8002A test fixture
