Kenwood C-V751 User Manual

22
Remote control of components from the GRC
Convenient functions
One-touch operation features
(Main unit only)
When the system is in standby mode, the operations as de-
scribed below are possible provided that the associated compo-
nents are connected through system control cords.
1 Ensure that system control cords are connected.
2 Load the source component with the software to be played.
3 Press the
(ON/STANDBY) key of the AV CONTROL
CENTER to put it to standby mode.
Preparations
1 Press the play key.
2 The system is switched from standby mode to ON mode.
3 The input selector is switched automatically.
4 Playback starts.
Function available with the play key operation
÷ CD player and cassette deck.
Operation available by switching the input
selector
1 Select the desired input with the input selector.
2 The selected source component starts to play.
÷ Turn on the system before switching the input selector.
(CD player, cassette deck (Single deck only), DVD player)
Easy operation feature
The operations as described below are possible provided that
the associated components are connected through system con-
trol cords.
÷ The STANDBY indicator lights in the STANDBY mode.
÷ Select the source component with the INPUT SELECTOR.

Kenwood C-V751 Specifications

General

harmonic distortion	0.01 %
signal to noise ratio	93 dB
sensitivity / impedance	200 mV / 47kΩ
controls S	± 10 dB (at 100 Hz)
BLE	± 10 dB (at 10 kHz)
level / impedance E REC	200 mV / 1 kΩ
composite	1 Vp-p/75 Ω
sampling frequency	32 kHz, 44.1 kHz, 48 kHz
input (coaxial)	0.5 Vp-p/75 Ω
optical	-15 dBm~-21 dBm, 600 nm ± 30 nm
frequency range	87.5 MHz~108 MHz
sensitivity (DIN) O	1.2 µV (at 75 Ω) / 13.2 dBf (40 kHz dev., S/N 26 dB)
sensitivity (DIN) REO	35 µV (at 75 Ω) / 42 dBf (46 kHz dev., S/N 46 dB)
signal to noise ratio (DIN weighted at 1 kHz, 40 kHz dev.) O	65 dB (65.2 dBf input)
signal to noise ratio (DIN weighted at 1 kHz, 40 kHz dev.) REO	60 dB (65.2 dBf input)
sensitivity (DIN ± 300 kHz)	64 dB
separation (DIN, 1 kHz)	36 dB
frequency response	30 Hz~15 kHz, + 0.5 dB, – 3.0 dB
tuning frequency range	531 kHz ~ 1, 602 kHz
usable sensitivity (30% mod., S/N 20 dB)	20 µV / (700 µV / m)
signal to noise ratio (at 30% mod. 1mV input)	48 dB
tuning frequency range	531 kHz ~ 1, 602 kHz
usable sensitivity (30% mod., S/N 20 dB)	20 µV / (700 µV / m)
signal to noise ratio (at 30% mod. 1mV input)	48 dB
tuning frequency range	153 kHz ~ 279 kHz
usable sensitivity (30% mod., S/N 20 dB)	35 µV
signal to noise ratio (at 30% mod. 1mV input)	45 dB
power consumption	35 W
dimensions (W x H x D)	400 mm x 105 mm x 382 mm
weight (net)	5.2 kg
weight (net) (For Australia)	5.1 kg
