Kenwood C-V751 User Manual

41
Listening to radio broadcasts
The AUTO MEMORY function gives precedence to RDS
stations and assigns them from preset number 1. Therefore,
when it is required to preset RDS stations as well as non-RDS
stations, execute the AUTO MEMORY operation first then
proceed to the manual memory operation of non-RDS sta-
tions.
Preparation
÷ Select the TUNER input. (
÷ Display the Tuner operation menu. (
Order of radio station presetting
Other stations than the RDS stations can be stored in the
preset memory by presetting them after the RDS stations
preset by AUTO MEMORY as shown below or overwrit-
ing the RDS stations preset in some preset numbers.
Preset number
1 2 39 40
1 AUTO MEMORY
RDS stations
(~ FM stations)
~
2 Manual memory
FM, MW or LW stations
FM, AM stations (Australia only)
Storing radio stations manually in preset memory
2 Press the “Memo” icon during receiving
a station.
3 Select the preset channel for use in pre-
setting the station.
÷ Apart from the auto memory function, radio stations can also be stored
manually in the preset memory.
÷ Repeat steps 1,2,3,4 for each of the stations to be stored in
memory.
÷ If a station is stored in a preset number which has already stored a
station memory under it, the previous memory is replaced by the new
memory content.
÷ If RDS stations are stored manually in the preset memory, the PS may
not be included in the memory depending on receiving conditions.
GRC
1 Perform step 1~4 of “Tuning radio sta-
tions”
°
4 Press the “Enter” icon.
(Select the icon)
÷ It is also possible to assign a station name to the manually preset
station.
5 Assigning a name to preset memory.
7 Press the “Name Input” icon to select the
name input mode.
To incresase
To decresase
8 Compose a name.
(Select the icon)
(Select the icon)
÷ Touch
to access to lowercase characters. Touch it again to
access special characters (such as @, !, &, etc.). Touch it a third time
to return to uppercase characters.
÷ Touch
or to move back and forth between the characters.
÷ Touch BS (Backspace) to clear the last caracter you entered. Touch
ALL DEL to delete all the characters in the line.
6 Select the preset channel to be named by
pressing
or .
÷ The name can be composed using up to 8 characters.
Continued to next page

Kenwood C-V751 Specifications

General

harmonic distortion	0.01 %
signal to noise ratio	93 dB
sensitivity / impedance	200 mV / 47kΩ
controls S	± 10 dB (at 100 Hz)
BLE	± 10 dB (at 10 kHz)
level / impedance E REC	200 mV / 1 kΩ
composite	1 Vp-p/75 Ω
sampling frequency	32 kHz, 44.1 kHz, 48 kHz
input (coaxial)	0.5 Vp-p/75 Ω
optical	-15 dBm~-21 dBm, 600 nm ± 30 nm
frequency range	87.5 MHz~108 MHz
sensitivity (DIN) O	1.2 µV (at 75 Ω) / 13.2 dBf (40 kHz dev., S/N 26 dB)
sensitivity (DIN) REO	35 µV (at 75 Ω) / 42 dBf (46 kHz dev., S/N 46 dB)
signal to noise ratio (DIN weighted at 1 kHz, 40 kHz dev.) O	65 dB (65.2 dBf input)
signal to noise ratio (DIN weighted at 1 kHz, 40 kHz dev.) REO	60 dB (65.2 dBf input)
sensitivity (DIN ± 300 kHz)	64 dB
separation (DIN, 1 kHz)	36 dB
frequency response	30 Hz~15 kHz, + 0.5 dB, – 3.0 dB
tuning frequency range	531 kHz ~ 1, 602 kHz
usable sensitivity (30% mod., S/N 20 dB)	20 µV / (700 µV / m)
signal to noise ratio (at 30% mod. 1mV input)	48 dB
tuning frequency range	531 kHz ~ 1, 602 kHz
usable sensitivity (30% mod., S/N 20 dB)	20 µV / (700 µV / m)
signal to noise ratio (at 30% mod. 1mV input)	48 dB
tuning frequency range	153 kHz ~ 279 kHz
usable sensitivity (30% mod., S/N 20 dB)	35 µV
signal to noise ratio (at 30% mod. 1mV input)	45 dB
power consumption	35 W
dimensions (W x H x D)	400 mm x 105 mm x 382 mm
weight (net)	5.2 kg
weight (net) (For Australia)	5.1 kg
