8119
Maintenance
Trunk room lamp replacement
1. Open the trunk lid.
2. Remove the lamp assembly by
using a flat-blade screwdriver.
3. Remove the cover from the lamp
assembly.
4. Remove the bulb by pulling it
straight out.
5. Install a new bulb in the socket.
6. Install the cover to the lamp
assembly.
7. Install the lamp assembly to the
body of the vehicle.
Tailgate room lamp bulb
replacement
1. Using a flat-blade screwdriver,
gently pry the lens cover from
lamp housing.
2. Remove the bulb by pulling it
straight out.
3. Install a new bulb in the socket.
4. Align the lens cover tabs with the
lamp housing notches and snap
the lens into place.
✽✽
NOTICE
If the LED lamp does not operate,
have your vehicle checked by a pro-
fessional workshop. Kia recom-
mends to visit an authorised Kia
dealer/service partner.
OND077040CN
CAUTION
Be careful not to dirty or dam-
age the lens, lens tab, and plas-
tic housings.
OJFW076213L
