Features of your vehicle
INSTRUMENT CLUSTER
1.
T
achometer
2.
Speedometer
3.
Engine coolant temperature gauge
4.
Fuel gauge
5.
W
ar
ning and indicator lights
6.
LCD display
OBD048154R/OBD048100R/OBD048101R
■
■
T
ype A (Petr
ol)
❈
The actual cluster in the vehicle ma
y
diff
er from the illustration.
F
or more details, refer to the
“Gauges”
in this chapter
.
■
■
T
ype B (Petr
ol)
■
■
T
ype C (Petr
ol)
79
81
