TP-5737 5/01 7Section 2 Operation
2.7 Decision-Makerä 3+ 16-Light Microprocessor Controller Operation
Figure 2-3 identifies the Decision-Makert 3+ 16-light controller’s indicators and controls and their functions.
ADV-5849 P1
12 34 5 6
8
9
1011121314151617
18
1. Fuses (inside controller)
2. Frequency meter
3. AC voltmeter
4. Controller TB1 and TB2 terminal strips (on circuit board)
5. AC ammeter
6. Scale lamps (upper/lower)
7. Selector switch
8. Annunciator panel lamps
9. Alarm silence switch
10. Lamp test
11. Generator set master switch
12. Alarm horn
13. DC voltmeter
14. Emergency stop switch, if equipped
15. Water temperature gauge
16. Voltage adjustment
17. Oil pressure gauge
18. Hourmeter
7
Figure 2 -3 Decision-Makert 3+, 16-Light Microprocessor Controller
