2.1
Section 2
Special Tools
2
Section 2
Special Tools
SV470-600
Some special tools for this engine are:
Flywheel Puller Kit ........................................................................................... NU3226
Valve Guide Reamer ......................................................................................... KO1026
Rocker Arm Spanner Wrench ........................................................................... (obtain locally)
Water Manometer ............................................................................................ KO1048
Vacuum Gauge ................................................................................................ KO3223
Cylinder Leakdown Tester................................................................................. KO3219
Ignition System Tester...................................................................................... KO1046
Amp Meter ....................................................................................................... KO3218
Inductance Tachometer .................................................................................... KO3216
Figure 2-1. Tool Catalog and Price List.
Certain quality tools are designed to help you perform specific disassembly, repair, and reassembly procedures.
By using tools designed for the job, you can service engines easier, faster, and safer! In addition, you’ll increase
your service capabilities and customer satisfaction by decreasing engine downtime.
Kohler special tools are handled by SPX Corp., a division of Owatonna Tool Corp. (OTC). The tools are easy to
purchase by contacting SPX/OTC by phone, fax, or mail.
Phone: 1-800-533-0492
International: 1-507-455-7223
8:00 am – 8:00 pm EST
Fax: 1-800-578-7375
1-586-578-7375
International: 1-507-455-7063
Mail: SPX Corp., OTC
28635 Mound Rd.
Warren, MI 48092-3499
Some of the specialty tools are shown and mentioned at various points in this manual. A complete catalog of all
available tools may be ordered under Kohler Part No. TP-2546. The tool price list is available under Kohler Part No.
TP-2547.
Special Tools You Can Make
Flywheel Holding Tool
Flywheel removal and reinstallation becomes a “snap”
using a handy holding tool you can make out of a piece
of an old “junk” flywheel ring gear as shown in Figure
2-2. Using an abrasive cut-off saw, cut out a six tooth
segment of the ring gear as shown. Grind off any burrs
or sharp edges. The segment can be used in place of a
strap wrench. Invert the segment and place it between
the ignition module bosses on the crankcase, so the
tool teeth engage the ring gear teeth on the flywheel.
The bosses will “lock” the tool and flywheel in position
for loosening, tightening or removing with a puller.
