Kohler KD62V12 User Manual

Repair
Exhaust gas system
Tightening specifications
Fig. 177: Exhaust pipes
Reference
Key
Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 230AI M8x1.25x20-C3J MH Yes 1 20 Nm
15 ft-lb
- -
2 412AB DIN 908 G1/4 A MH No 1 30 Nm
22 ft-lb
- -
3 412AD M12x1.75x50-C3J - Yes 1 56 Nm
41 ft-lb
- -
4 430AA DIN 939 M10x1.5x22 MH Yes 1 24 Nm
18 ft-lb
- -
Tab. 35: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse,
and marking, page 268.)
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
165
