Repair
Driving gear
3.7 Driving gear
3.7.1 Power unit
Endoscopy - Combustion chambers (SL 206)
Previous tasks
Make sure that the following preconditions are met:
q Cylinder head covers are removed. (For more information see: 3.4.3 Cylinder head cover
removal and installation, page 64.)
q Injectors are removed. (For more information see: 3.8.4 Injector removal and installation (SL
205), page 121.)
Specific safety instructions
Not applicable.
Special tools
Make sure that the following tools are available:
– Turning device
(For more information see: 4.1.1 Special tools, page 258.)
Consumables and equipment
Not applicable
Overview
Fig. 94: Task overview
1
Exhaust side 2 Admission side
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
97
